Workpiece: |
Angle encoder |
Task: |
Development, design, manufacture, assembly and commissioning of a fully automated system for the machining, assembly and testing of angle encoders. |
Solution: |
Pre-assembled sensors are first inserted manually and then fed to the system by means of pneumatic handling. A Scara robot with feeder unit takes over the indexing of the actuating levers. The parts are transported to the machining station via a rotary indexing table. First, levers and sensors are automatically pre-bolted together.
In further stations, hot riveting with infrared technology creates an inseparable joint. After the functional test, the n.o.k. parts are discharged from the process via a chute. |
Customer benefits: |
High quantities due to short cycle times Parallel processing of two sensors at a time (double nests) and multiple stations for long process steps (total for max. 8 hot riveting stations), remote maintenance interface for process analysis and software monitoring or correction |
Angle encoder
Development, design, manufacture, assembly and commissioning of a fully automated system for the machining, assembly and testing of angle encoders.
Pre-assembled sensors are first inserted manually and then fed to the system by means of pneumatic handling. A Scara robot with feeder unit takes over the indexing of the actuating levers. The parts are transported to the machining station via a rotary indexing table. First, the lever and sensors are automatically pre-bolted together.
In further stations, hot riveting with infrared technology creates an inseparable joint. After the functional test, the n.o.k. parts are discharged from the process via a chute.
High quantities due to short cycle times Parallel processing of two sensors at a time (double nests) and multiple stations for long process steps (total for max. 8 hot riveting stations), remote maintenance interface for process analysis and software monitoring or correction
